Product Descriptions
Features
●Low insertion loss, low polarization related loss;
●Compact and exquisite design, good spectral uniformity;
●Wide working wavelength range (1260nm-1650nm);
●Wide working temperature range (-40 ℃ -85 ℃);
●High stability and reliability.
Specifications (2XN)
|
Parameters |
2×2 |
2×4 |
2×8 |
2×16 |
2×32 |
2×64 |
2×128 |
|
|
Operating wavelength |
1260 ~1650nm |
|||||||
|
Insertion Loss (dB)(P/S Grade) |
3.8/4.2 |
7.5/7.8 |
10.7/11 |
14/14.2 |
17/17.5 |
21/21.5 |
25/25.5 |
|
|
uniformity (dB) |
0.6 |
1.0 |
1.2 |
1.5 |
1.8 |
2.0 |
2.5 |
|
|
PDL (dB) |
0.2 |
0.2 |
0.3 |
0.3 |
0.3 |
0.4 |
0.4 |
|
|
Return Loss (dB) |
≥55 |
|||||||
|
Directivity (dB) |
≥55 |
|||||||
|
TDL (dB) |
0.5 |
|||||||
|
Operating/Storage Temperature (℃) |
-40~85 |
|||||||
Note: All the data above does not include connector
applications
● Long distance transmission, user loop;
● Fiber to the home, cable TV network, telecommunications;
● Fiber optic sensors, data communication;
● PON network, wide area network
