Product Introduction

Fiber optic LC adapter, also known as a coupler, is a small device designed to terminate or link a fiber optic cable or fiber optic connector between two fiber optic lines. By precisely connecting the two connectors, the fiber optic LC adapter transmits the light source with minimal loss. At the same time, the fiber adapter has the advantages of low insertion loss, good interchangeability and reproducibility.

Specification

insertion loss(dB)	≤ 0.20
Duplication (dB)	≤ 0.10
Interchangeability (dB)	≤ 0.20
Sleeve material	Ceramics
Operating temperature (℃)	-25 ~ +70/-40 ~ +80/-25~+70
Storage temperature (℃)	-40 ~ +85

Features

The LC adapter minimizes insertion loss, which is the amount of light lost as it passes through the connector. This helps maintain signal quality and reduces the need for amplification.

It has a high return loss and reflects the amount of light back to the light source. This helps prevent interference and maintain signal strength.

Its small size makes it ideal for high-density applications such as data centers and LAN/WAN networks
